Fenner Dunlop X Series

Premium line of single carcass construction conveyor belts.

Discover Fenner Dunlop conveyor belts, specifically engineered to last longer.

Watch the introduction or Go to Fenner Dunlop Americas

Moving
your business
forward

No more need for multi ply belting

Historically, conveyor belts have been manufactured using two or more plies of fabric that are adhered to each other using inner layers of rubber. When additional rip, tear and impact resistance was required for a more demanding bulk material handling application, the obvious answer seemed to be fitting a belt with even more plies with even thicker covers. Which was proved to be very rarely the best solution. The best solution is to fit belts that are specifically engineered for the purpose, which is the philosophy that X Series is based on.

Made in North America Read the brochure

3 levels of the toughness.
2 carcasses types

Unique weave styles designed especially for your bulk material handling needs.

  • X Series Straight-Warp carcass

    Straight-Warp

    Our parallel planes reinforce like the multiple plies of traditional belts but without the crimping that weakens and stretches the yarn. Our binder is a built-in breaker to resist impacts and punctures.

  • X Series Straight-Warp carcass

    Dual-Crimp

    The fabric construction and treatment process result in enhanced resistance to edge ravel, moisture, mildew and acid mine water.

the toughest

UsFlex

Super heavy-duty conveyor belts

Applications

Heavy duty bulk material handling applications

Carcass

Revolutionary straight-warp weave carcass

UsFlex stands apart from the competition. We use heavyweight straight yarns in parallel planes – lengthwise and crosswise – locked together with a unique binder to concentrate belt strength. Our parallel planes reinforce like the multiple plies of traditional belts but without the crimping that weakens and stretches the yarn. Our binder is a built-in breaker to resist impacts and punctures.

  • Up to 3150 N/mm (2000 PIW)
  • Revolutionary Straight-Warp conveyor belt
  • up to 2x greater rip resistance
Learn more about UsFlex
Conveyor belts for crusher.

For conveyor belts that follow primary and secondary crusher.

tougher

Nova-X

Innovative flexible core fabric conveyor belt

Applications

Medium to heavy duty bulk material handling

Carcass

Dual crimp weave carcass

The Nova-X carcass can handle tougher aggregate applications from sand to gravel to primary and secondary crushers. A flexible belt core and technologically advanced solution for faster, more reliable bulk material conveyors. Excellent resistance to rip, tear and impact puncture thanks to a technologically advanced and patented fabric belt design.

  • Up to 1250 N/mm (800 PIW)
  • Patented dual crimp weave for higher strength and low stretch applications
  • Unique fabric weave allows for improved mechanical fastener retention & splice life
Learn more about Nova-X
Conveyor belts for high heat environment

Available in Xtreme variant designed for unbearable heat environment.

tough

Ultra X

Light and medium duty bulk material handling

Applications

General light and medium duty bulk material handling

Carcass

Dual crimp weave carcass

Single unit construction with patented dual crimp weave design offers superior carcass adhesion in both wet and dry applications. Improved rip, tear, and impact resistance compared to import and typical domestic belting products. Excellent mechanical fastener retention and can utilize Fenner Dunlop finger splice technology.

  • Up to 640 N/mm
  • Available in 275, and 350 PIW constructions
  • General light and medium duty bulk material handling applications
Learn more about Ultra X
Economic solution

A great replacement for import belts: delivering superior quality and enhanced longevity.

Case Studies & Engineers Testimonials

What engineers say about X Series

We are famous for manufacturing the longest lasting conveyor belts in the world, but we don’t want you to simply take our word for it. Please check out some real-life case studies below.

Ultra X conveyor belts for quarry industry
#Ultra X #Quarry
UsFlex Unmatched Performance for Mobile Crushers
#UsFlex #Mobile Crushers
case study
#Ultra X #Aggregates
X Series Conveyor Belts are produced in Europe and US

The longest lasting conveyor belts in the world made in North America and EU

We have invested more than $100 MM in our North American plants, including boasting the longest press in the world, a state of the art pressure equalizer that allows an even pressure applied to the entire belt vs. older technology. We are really proud of our new calender machine from Germany that has the latest hard pressure rollers to finish and smooth our carcass and cover compounds.

X Series Conveyor Belts are produced in Europe and US
